Multiblade Fire Damper
Merchandise number：FD-5000
Description：
- UL Listings-File：EMME R40105
- Depth：100mm
- Frame：16 GA Galvanized Steel
- Blades：22 GA Galvanized Steel
- Blades operation type：Parallel
- Minimum size：150mm×150mm
◎ Specifications (4"/2000FPM)
| Static | Single Size (Maximum) |
Multiple Size (Maximum) |
|||
| Fire Rating | Mounting Position | W | H | W | H |
| 1.5hr | Vertical | 914 | 1143 | 3658 | 2286 |
| Horizontal | 914 | 1143 | 3658 | 2286 | |
| 3hr | Vertical | 762 | 762 | - | - |
| Dynamic | Single Size (Maximum) |
Multiple Size (Maximum) |
|||
| Fire Rating | Mounting Position | W | H | W | H |
| 1.5hr | Vertical | 914 | 1143 | 1829 | 1143 |
| Horizontal | 914 | 1143 | 1829 | 1143 | |
| 3hr | Vertical | 762 | 762 | - | - |
